Fusion Apollo MS-RA800 Marine Stereo

Part Number 010-02937-00

BUY NOW

Feature
Specs
In The Box
Update
Accessories

OUR MOST ADVANCED MARINE STEREO EVER

It’s the most powerful and technologically advanced Fusion^® marine stereo ever. With audiophile-level components and a built-in amplifier providing twice the power of the predecessor RA770, this system delivers lossless audio performance of unmatched clarity. Plus, its Wi-Fi^® connectivity supports seamless AirPlay^® audio streaming on your boat.

SLEEK, MODERN DESIGN FEATURES EDGE-TO-EDGE GLASS DISPLAY

ENJOY PREMIUM WI-FI STREAMING WITH HIGH-RESOLUTION LOSSLESS AUDIO

BUILT-IN CLASS-D AMPLIFIER BOASTS 50% MORE POWER OUTPUT¹

SEE QUICKER RESPONSE WITH 8 TIMES FASTER DIGITAL PROCESSING SPEED¹

SHARE ONBOARD AUDIO SOURCES WITH STEREO GROUPING

REMOTELY CONTROL YOUR MUSIC FROM COMPATIBLE DEVICES

WHAT YOU'LL LOVE

HIGH-RESOLUTION AUDIO

Our first marine stereo to support high-resolution lossless audio (up to 24 bits at 96 kHz), RA800 offers unparalleled sound quality — supported by Wi-Fi technology for seamless audio streaming.

UPGRADED INTERNAL AMP

The built-in Class-D amplifier can deliver 4 x 40 watts RMS (all channels driven) with less than 0.1% total harmonic distortion at 4 ohms — producing more than 50% more power output¹ than its predecessor.

HIGHER-RESOLUTION DISPLAY

The stereo’s 4.3-inch LCD touchscreen display offers notable improvements¹ in image resolution, color saturation, viewing angles and readability in bright daylight.

STEREO NETWORKING

Connect your RA800 with other Apollo Series stereos to create a network on board your boat. Enjoy advanced features including stereo grouping, combined volume control, power options and Home Zone control.

MULTIPLE SOURCE OPTIONS

Take advantage of a wide variety of source options available, including AirPlay streaming from Apple^®, BLUETOOTH^® connectivity, HDMI ARC, DAB+ radio tuner, USB connections, AM/FM radio and AUX inputs.

MFD NETWORKING

Easily network your RA800 stereo with a compatible Garmin MFD via NMEA 2000 networking for integrated audio control at the helm. Or use the Fusion Audio app to wirelessly control your music from a compatible Garmin smartwatch or other smart device.

EASY-FIT INSTALLATION

QUICK SWITCH FROM RA770 TO RA800

With an identical form factor and wiring loom as the predecessor RA770, upgrading and installation are simple with RA800.

ADVANCED AUDIO PERFORMANCE

AUDIO STREAMING WITH WI-FI

Built-in Wi-Fi connectivity for AirPlay audio streaming, combined with multiple-input multiple-output technology, offers a seamless high-fidelity listening experience.

ONE-PIECE GLASS TOUCH DISPLAY

An intuitive menu-driven interface and edge-to-edge glass touchscreen let you simply tap or swipe the display for easy control of stereo functions.

MODERN DESIGN AND AESTHETICS

The stereo’s black glass faceplate can be flush mounted to blend seamlessly with other electronics at the helm.

ENGINEERED FOR HARSH MARINE ENVIRONMENTS

Built on the True-Marine^™ design philosophy from Fusion, RA800 has an IPX6- and IPX7-rated water-resistant front panel and has been tested to a high level of protection against salt fog, temperature, vibration and UV exposure.

DIGITAL SIGNAL PROCESSING (DSP)

A technically superior listening experience made simple,Fusion DSP optimizes the audio signal delivered to your Fusion system to produce superior sound quality at all volume levels, in every listening environment.

EASY-TO-INSTALL DSP PROFILES

With the free Fusion Audio app on your smartphone, you can set up the preconfigured DSP profiles once and enjoy high-quality audio customized for your listening environment.

A SUPERIOR LISTENING ENVIRONMENT

STEREO GROUPING

Grouping allows you to link up multiple Apollo Series stereos connected to the same network and play the same audio source synchronized across all stereos.

VOLUME CONTROL

Scroll through available zones on your boat, and enjoy independent volume control, or select ALL volume to adjust a group of stereos at once.

POWER OPTIONS

Power options allow you turn on any connected Apollo Series stereo in standby mode on the Fusion stereo network remotely from another Apollo Series stereo.

HOME ZONE

Home Zone is the physical zone in which the stereo is installed on board your boat. After adjusting audio in another zone, the stereo defaults to control of the Home Zone after a period of inactivity.

OVER-THE-AIR SOFTWARE UPDATES

Updates are available from your compatible smartphone or device, via the free Fusion Audio app. Apollo Series stereos are easy to keep up to date².

SPEED VS. VOLUME

Selecting Speed vs. Volume from the stereo’s Settings menu enables audio volume to be automatically adjusted based on your boat’s speed³. Faster equals louder; slower equals lower volume.

¹Compared to predecessor RA770 model

²Available when connected to a wireless network router, Garmin MFD or Apollo Series stereo network enabled with Wi-Fi technology

³Requires connection to an NMEA 2000 network with an appropriate speed sensor installed

Wi-Fi is a registered trademark of the Wi-Fi Alliance. AirPlay and Apple are trademarks of Apple Inc., registered in the U.S. and other countries. The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Garmin is under license.

TRUE-MARINE PHILOSOPHY Any product that bears the Fusion True-Marine seal of assurance has been designed by Fusion to withstand the harshest marine environments season after season and comes with an industry-leading 3-year warranty.

General
Physical dimensions (Height)	3.23" (82 mm)
Physical dimensions (Width)	7.56" (192 mm)
Physical dimensions (Depth)	4.7" (119.4 mm)
Weight	1.37 lbs (620 g)
Control Surface Dust/Water Rating (when properly installed)	IPX6 and IPX7
Rear Dust/Water Rating (when properly installed)	IPX3
Operating temperature range	-20 to 70° C
Current draw (max)	25 A at 14.4 V; 15A at 28.8 V
Warranty	3 years
Networking
NMEA 2000® LEN	2 (65 mA)
BLUETOOTH® wireless range	up to 30 ft (10 meters)
ANT® wireless range	Up to 10 ft (3 meters)
Wireless frequencies/protocols	WiFi 2.4Ghz : +12dBm nominal MIMO 2 x 2 BLUETOOTH®: 2.4 GHz @ +10 dBm nominal ANT®: 2.4GHz 0dBm nominal
Audio
Rated continuous (RMS) power (14.4 V input @ 4 Ohm < 1% THD)	40 W x 4
Electrical Features
Power Input	10.8 to 32 Vdc
Compass safe distance	5.9" (150 mm)
Stereo Features
Display size	4.3" (109 mm)
Display type	capacitive touchscreen color LCD
Display resolution	800 x 480
Optically bonded display	yes
Built-in amplifier	Class D (4 Ω)
Built-in Wi-Fi®
Built-in Digital Signal Processing (DSP)	yes (with custom DSP profile setup using Fusion-Link™ app)
Fusion-Link™ control	yes (MFD, smart device and Garmin watch)
Multi-Zone™ technology	4 zones
BLUETOOTH® wireless technology
ANT® wireless technology
DAB+ ready
Multi-language interface	Bulgarian, Chinese (Simplified), Chinese (Traditional), Croatian, Czech, Danish, Dutch, English, Finnish, French, German, Greek, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (BR), Portuguese (PT), Slovenian, Spanish, Swedish, Thai, Turkish
Software updates	Over-the-air updates via Fusion-Link™ app (when connected to wireless network router) / USB
Sources
Supported sources	AM, FM, BLUETOOTH®, Apple AirPlay® 2, HDMI ARC, USB audio, iPhone, iPod, AUX x2
Supported audio formats (USB)	MP3, AAC, M4A, FLAC, WAV
Connections
Auxiliary inputs (RCA)	2
HDMI ARC Ports	1
Ethernet ports	1
NMEA 2000® ports	1
USB 2.0 ports	1 (USB-C)
AM/FM ports (Motorola antenna connector)	1
Speaker connections	4 (2 zone amplified)
RCA pre-out (left, right and subwoofer - requires external amplification)	4 zones
Line out (requires external amplification)	4 (L + R per zone)
Subwoofer out (requires external amplification)	4 (1 mono output per zone)

Fusion Apollo^™ MS-RA800 marine stereo
Mounting gasket
Four 8-gauge self-tapping screws
Two screw covers
Power and speaker wiring harness
Auxiliary-in, line-out and subwoofer-out wiring harnesses
6 ft (2 m) drop cable for the NMEA 2000^® network
Dust cover
Documentation
