Discontinued

Vector™ 2

Part Number 010-01455-04

ONLINE STORE

Feature
Specs
In The Box
Update
Accessories
Compatible Devices

Pedal-based Power Meter

Dual-sensing pedal-based power meter
Measures total power, left/right balance and cadence
Displays cycling dynamics showing how and where power is produced
Installs in minutes and quickly transfers between bikes
Pedal pods include an LED light to display important setup and maintenance information

Vector 2

Measure Where it Matters

Power is the most reliable way to gauge cycling performance on any given day, at any given time. Vector 2 revolutionizes how power is measured and how cyclists get that power data. Unlike other power meters, Vector 2 measures power at the pedal, where force is applied. It’s a direct-measurement power meter that delivers reliable, accurate data. And because the force sensors are housed in each pedal, Vector 2 gives you the unique ability to see right and left leg power independently.

Train Smarter with Cycling Dynamics

Factors like fatigue, fitness, injury and recovery all affect the way you ride. Revolutionary new cycling dynamics lets you tailor your training around your specific weaknesses and strengths by showing you exactly where you’re generating power throughout the pedal stroke. It also indicates where force is being applied on the pedal itself so you can ensure proper cleat position, as well as when and how long you were seated versus standing so you can gauge position effectiveness.

Easy to Buy, Install, Transfer

In the past, power meters were difficult to install and often involved making mechanical tradeoffs for your bike. But with Vector 2, you can walk into your local bike shop, purchase a Vector 2 power meter and install it yourself in minutes. There’s no need for a mechanic, or no downtime while your bike is in the shop. There are no complex drivetrain or wheel tradeoffs, or no external sensors to install. Plus, unlike its predecessor, there are no tricky washers to worry about. That means you can even swap it between bikes quickly if you desire.

With additional crank arm clearance — in thickness and width — Vector 2 fits almost any bike. The standard pedal pods fit crank arms 12 to 15 mm thick and 44 mm wide. The large pedal pods fit crank arms 15 to 18 mm thick and up to 44 mm wide.

Complete Cycling Suite

Vector 2 works in tandem with a compatible cycling computer or other fitness device to take your training to the next level. While you ride, Vector 2 measures total power, left and right leg power, cadence and cycling dynamics, and sends the data to compatible ANT+® enabled devices¹ for viewing. Post-ride analysis, data sharing, mapping, route planning and more can also be integrated into your training through Garmin Connect™.

Connected Bike

Edge 1000 GPS bike computer
VIRB Elite action camera
Vector power meter
Shimano Di2 electronic shifting system
heart rate monitor
speed sensor
Edge remote control
smartphone with Garmin Connect Mobile app

¹See Specs to see data that can be viewed on compatible devices.

WARNING: The maximum weight limit of the cyclist using the Vector 2 system is 200 lbs (90 kg). Cyclists over this weight limit risk personal injury and property damage.

Manual Download Vector Code

Dedicated Website

Vector System

Battery life: 175 hours
Weight (approximate, per pedal):
- Pedal body: 156 g
- Pedal pod: 23 g
- Cleat and hardware: 38 g
- Total: 179 g (not including cleats and hardware)

Pedal Body and Assembly

Lightweight composite body
Stainless steel wearplate
CNC machined, hardened stainless steel spindle
Bushing and sealed cartridge bearings
Adjustable tension binding
LOOK Kéo-compatible¹

Pedal Pods

ANT+™ transmitters
User-replaceable battery (2032 coin cell)
Minimum of 175 hours of active cycling operation

Cleats

High durability thermoplastic with anti-slip rubber surface pads
Rubber button to reduce free float action between shoe and cleat
6 degrees of float (0 degree also available)
LOOK Kéo-compatible¹

¹LOOK and Kéo marks are the property of LOOK Cycle International

Vector 2 pedals
2 pedal pods
Cleats and hardware
Crowfoot installation tool
USB ANT+ Stick™
Manuals
