Pedal-based Power Meter

Measures power output at the pedal, where force is applied
Left/right balance: average at various time intervals
Measures cadence, total power (watts), intensity factor
Install it yourself in minutes
Easily transferable between bikes
ANT+™ wireless protocol

Measure Where It Matters

Garmin brings power to the people with Vector, an innovative pedal-based power meter. It not only changes how power is measured; it changes how cyclists get power — making it extremely easy to buy and install. Vector measures power at the pedal, where force is applied. It’s a direct measurement power meter that delivers reliable, accurate data. Because the force sensors are housed in each pedal, Vector gives you the unique ability to see right and left leg power independently.

Easy to Buy, Install, Own

In the past, owning a power meter was a complicated process and often involved making mechanical tradeoffs for your bike. Vector changes all of that. Now you can walk into your local bike shop, walk out with a Vector power meter in hand, and then install it yourself in minutes. There’s no need for a mechanic, no downtime while your bike is in the shop. Plus, there are no complex drivetrain or wheel tradeoffs to consider and no external sensors to install. See if Vector fits your crank.

Another advantage of Vector is that you can use the same system on multiple bikes by simply swapping out pedals and moving the wireless head unit. And, you can take Vector with you when you’re going out of town for a race or when you’re traveling and might be renting or borrowing a bike. It’s also easy to update Vector software as enhancements are made, thanks to its ANT+™ wireless technology.

Wizardry Behind the Watts

Vector works by measuring the deflection in the pedal spindle as you pedal. By comparing that measured deflection to a factory-calibration, Vector can determine how much force you’re applying to the pedal. Vector measures the force you apply a few hundred times every second. Built-in accelerometers also measure your pedaling cadence. The force sensor and related electronics are permanently and securely sealed within the pedal spindle.

Complete Cycling Suite

If you’re already using a compatible Garmin head unit such as the Garmin Edge 500, 510, 800, 810 or Forerunner 910XT, adding a Vector power meter will take your training to the next level. Vector measures total power, left and right leg power and cadence and sends the data to compatible Edge cycling computers or other ANT+ enabled head units¹. Complete the suite with post-ride analysis, mapping, route planning and data sharing at Garmin Connect. Having all your cycling electronics and analysis from one brand means you can trust the equipment, the user experience and the support.

¹ See the "Specs" tab for information about what data can be viewed on compatible Garmin devices.

Vector System

Battery life: 175 hours
Weight (approximate, per pedal):
- Pedal: 152 g
- Pedal pod: 23 g
- Cleats and hardware: 38 g
- Total per pedal: 213 g

Pedal Body and Assembly

Lightweight composite body
Stainless steel wearplate
CNC machined, hardened stainless steel spindle
LSL bushing and sealed cartridge bearings
Adjustable tension binding
LOOK Kéo-compatible¹

Pedal Pods

ANT+™ transmitters
User-replaceable battery (2032 coin cell)
Minimum of 175 hours of active cycling operation

Cleats

High durability thermoplastic with anti-slip rubber surface pads
Rubber button to reduce free float action between shoe and cleat
6 degrees of float (0 degree also available)
LOOK Kéo-compatible¹

¹LOOK and Kéo marks are the property of LOOK Cycle International

Vector pedals
Pedal pods
Cleats and hardware
USB ANT Stick
Manuals
